Step1: Product
Vigortronix VTX-101-1634
Images are for reference only
Manufacturer
Manufacturer No
VTX-101-1634
Packaging
Bulk
Description
AUDIO XFMR ENCAP MATCH
Detailed Description
150 Impedance Primary Ohms 600 Impedance Secondary Ohms Audio Transformer 60Hz ~ 25kHz Through Hole
Datasheet
Payment
Delivery
Series
VTX-101
Packaging
Bulk
Manufacturer
Vigortronix
Mounting Type
Through Hole
Approval Agency
-
Frequency Range
60Hz ~ 25kHz
Size / Dimension
0.709" L x 0.709" W (18.00mm x 18.00mm)
Transformer Type
Miniature Epoxy Potted
Termination Style
PC Pin
Voltage - Isolation
500Vrms
Height - Seated (Max)
0.500" (12.70mm)
Impedance - Primary (Ohms)
150
Impedance - Secondary (Ohms)
600
DC Resistance (DCR) - Primary
31Ohm
DC Resistance (DCR) - Secondary
33Ohm
| Attribute | Value |
|---|---|
| Series | VTX-101 |
| Packaging | Bulk |
| Manufacturer | Vigortronix |
| Mounting Type | Through Hole |
| Approval Agency | - |
| Frequency Range | 60Hz ~ 25kHz |
| Size / Dimension | 0.709" L x 0.709" W (18.00mm x 18.00mm) |
| Transformer Type | Miniature Epoxy Potted |
| Termination Style | PC Pin |
| Voltage - Isolation | 500Vrms |
| Height - Seated (Max) | 0.500" (12.70mm) |
| Impedance - Primary (Ohms) | 150 |
| Impedance - Secondary (Ohms) | 600 |
| DC Resistance (DCR) - Primary | 31Ohm |
| DC Resistance (DCR) - Secondary | 33Ohm |
