Texas Instruments DRV8952PWPR
Images are for reference only
Manufacturer
Manufacturer No
DRV8952PWPR
Quantity
19
Availability
In Stock
Package
28-PowerTSSOP (0.173", 4.40mm Width)
Packaging
Tape & Reel (TR)
Description
50-V FOUR-CHANNEL HALF-BRIDGE DR
Detailed Description
Half Bridge (4) Driver DC Motors, General Purpose NMOS 28-HTSSOP
Datasheet
Payment
Delivery
Grade
-
Series
-
Features
Charge Pump
Interface
PWM
Load Type
Inductive, Capacitive, Resistive
Packaging
Tape & Reel (TR)
Technology
NMOS
Applications
DC Motors, General Purpose
Manufacturer
Texas Instruments
Rds On (Typ)
55mOhm LS, 58mOhm HS
Mounting Type
Surface Mount
Qualification
-
Package / Case
28-PowerTSSOP (0.173", 4.40mm Width)
Voltage - Load
4.5V ~ 55V
Fault Protection
Current Limiting, Over Temperature, UVLO
Voltage - Supply
3.05V ~ 5.5V
Output Configuration
Half Bridge (4)
Current - Peak Output
4A
Operating Temperature
-40°C ~ 125°C (TA)
Supplier Device Package
28-HTSSOP
Current - Output / Channel
4A
| Attribute | Value |
|---|---|
| Grade | - |
| Series | - |
| Features | Charge Pump |
| Interface | PWM |
| Load Type | Inductive, Capacitive, Resistive |
| Packaging | Tape & Reel (TR) |
| Technology | NMOS |
| Applications | DC Motors, General Purpose |
| Manufacturer | Texas Instruments |
| Rds On (Typ) | 55mOhm LS, 58mOhm HS |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 28-PowerTSSOP (0.173", 4.40mm Width) |
| Voltage - Load | 4.5V ~ 55V |
| Fault Protection | Current Limiting, Over Temperature, UVLO |
| Voltage - Supply | 3.05V ~ 5.5V |
| Output Configuration | Half Bridge (4) |
| Current - Peak Output | 4A |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Supplier Device Package | 28-HTSSOP |
| Current - Output / Channel | 4A |
