Texas Instruments DRV8955PRGER
Images are for reference only
Manufacturer
Manufacturer No
DRV8955PRGER
Date Code
2046
Quantity
2,573
Availability
In Stock
Package
24-VFQFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC HALF BRIDGE DRIVER 10A 24VQFN
Detailed Description
Half Bridge (4) Driver DC Motors, Solenoids, Stepper Motors Power MOSFET 24-VQFN (4x4)
Datasheet
Payment
Delivery
Series
-
Features
Charge Pump
Interface
Logic, PWM
Load Type
Inductive, Capacitive, Resistive
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Power MOSFET
Applications
DC Motors, Solenoids, Stepper Motors
Manufacturer
Texas Instruments
Rds On (Typ)
165mOhm
Mounting Type
Surface Mount
Package / Case
24-VFQFN Exposed Pad
Voltage - Load
4.5V ~ 48V
Fault Protection
Over Current, Over Voltage, UVLO
Voltage - Supply
4.5V ~ 48V
Base Product Number
DRV8955
Output Configuration
Half Bridge (4)
Current - Peak Output
10A
Operating Temperature
-40°C ~ 125°C (TA)
Supplier Device Package
24-VQFN (4x4)
Current - Output / Channel
10A
| Attribute | Value |
|---|---|
| Series | - |
| Features | Charge Pump |
| Interface | Logic, PWM |
| Load Type | Inductive, Capacitive, Resistive |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Power MOSFET |
| Applications | DC Motors, Solenoids, Stepper Motors |
| Manufacturer | Texas Instruments |
| Rds On (Typ) | 165mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad |
| Voltage - Load | 4.5V ~ 48V |
| Fault Protection | Over Current, Over Voltage, UVLO |
| Voltage - Supply | 4.5V ~ 48V |
| Base Product Number | DRV8955 |
| Output Configuration | Half Bridge (4) |
| Current - Peak Output | 10A |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Supplier Device Package | 24-VQFN (4x4) |
| Current - Output / Channel | 10A |
