Step1: Product
Fairchild Semiconductor FDMA1028NZ
Images are for reference only
Manufacturer
Manufacturer No
FDMA1028NZ
Quantity
10
Availability
In Stock
Package
6-VDFN Exposed Pad
Packaging
Bulk
Description
MOSFET 2N-CH 20V 3.7A 6MICROFET
Detailed Description
Mosfet Array 20V 3.7A 700mW Surface Mount 6-MicroFET (2x2)
Datasheet
Payment
Delivery
Series
PowerTrench®
Packaging
Bulk
Technology
MOSFET (Metal Oxide)
FET Feature
Logic Level Gate
Power - Max
700mW
Manufacturer
Fairchild Semiconductor
Configuration
2 N-Channel (Dual)
Mounting Type
Surface Mount
Package / Case
6-VDFN Exposed Pad
Vgs(th) (Max) @ Id
1.5V @ 250µA
Base Product Number
FDMA1028
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
68mOhm @ 3.7A, 4.5V
Supplier Device Package
6-MicroFET (2x2)
Gate Charge (Qg) (Max) @ Vgs
6nC @ 4.5V
Drain to Source Voltage (Vdss)
20V
Input Capacitance (Ciss) (Max) @ Vds
340pF @ 10V
Current - Continuous Drain (Id) @ 25°C
3.7A
| Attribute | Value |
|---|---|
| Series | PowerTrench® |
| Packaging | Bulk |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | Logic Level Gate |
| Power - Max | 700mW |
| Manufacturer | Fairchild Semiconductor |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Package / Case | 6-VDFN Exposed Pad |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Base Product Number | FDMA1028 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 68mOhm @ 3.7A, 4.5V |
| Supplier Device Package | 6-MicroFET (2x2) |
| Gate Charge (Qg) (Max) @ Vgs | 6nC @ 4.5V |
| Drain to Source Voltage (Vdss) | 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 340pF @ 10V |
| Current - Continuous Drain (Id) @ 25°C | 3.7A |
