Step1: Product
Wolfspeed, Inc. CCB021M12FM3
Images are for reference only
Manufacturer
Manufacturer No
CCB021M12FM3
Availability
In Stock
Package
Module
Packaging
Tray
Description
MOSFET 6N-CH 1200V 51A
Detailed Description
Mosfet Array 1200V (1.2kV) 51A Chassis Mount
Datasheet
Payment
Delivery
Series
WolfPACK™
Packaging
Tray
Technology
Silicon Carbide (SiC)
FET Feature
-
Power - Max
-
Manufacturer
Wolfspeed, Inc.
Configuration
6 N-Channel (3-Phase Bridge)
Mounting Type
Chassis Mount
Package / Case
Module
Vgs(th) (Max) @ Id
3.6V @ 17.7mA
Base Product Number
CCB021
Operating Temperature
-40°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
27.9mOhm @ 30A, 15V
Supplier Device Package
-
Gate Charge (Qg) (Max) @ Vgs
162nC @ 15V
Drain to Source Voltage (Vdss)
1200V (1.2kV)
Input Capacitance (Ciss) (Max) @ Vds
4900pF @ 800V
Current - Continuous Drain (Id) @ 25°C
51A
| Attribute | Value |
|---|---|
| Series | WolfPACK™ |
| Packaging | Tray |
| Technology | Silicon Carbide (SiC) |
| FET Feature | - |
| Power - Max | - |
| Manufacturer | Wolfspeed, Inc. |
| Configuration | 6 N-Channel (3-Phase Bridge) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Vgs(th) (Max) @ Id | 3.6V @ 17.7mA |
| Base Product Number | CCB021 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 27.9mOhm @ 30A, 15V |
| Supplier Device Package | - |
| Gate Charge (Qg) (Max) @ Vgs | 162nC @ 15V |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Input Capacitance (Ciss) (Max) @ Vds | 4900pF @ 800V |
| Current - Continuous Drain (Id) @ 25°C | 51A |
