Step1: Product
Wolfspeed, Inc. CAB530M12BM3
Images are for reference only
Manufacturer
Manufacturer No
CAB530M12BM3
Availability
In Stock
Package
Module
Packaging
Tray
Description
MOSFET 2N-CH 1200V 530A MODULE
Detailed Description
Mosfet Array 1200V (1.2kV) 530A Chassis Mount Module
Datasheet
Payment
Delivery
Series
-
Packaging
Tray
Technology
Silicon Carbide (SiC)
FET Feature
-
Power - Max
-
Manufacturer
Wolfspeed, Inc.
Configuration
2 N-Channel (Dual)
Mounting Type
Chassis Mount
Package / Case
Module
Vgs(th) (Max) @ Id
3.6V @ 140mA
Base Product Number
CAB530
Operating Temperature
-40°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
3.55mOhm @ 530A, 15V
Supplier Device Package
Module
Gate Charge (Qg) (Max) @ Vgs
1362nC @ 4V
Drain to Source Voltage (Vdss)
1200V (1.2kV)
Input Capacitance (Ciss) (Max) @ Vds
39600pF @ 800V
Current - Continuous Drain (Id) @ 25°C
530A
| Attribute | Value |
|---|---|
| Series | - |
| Packaging | Tray |
| Technology | Silicon Carbide (SiC) |
| FET Feature | - |
| Power - Max | - |
| Manufacturer | Wolfspeed, Inc. |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Vgs(th) (Max) @ Id | 3.6V @ 140mA |
| Base Product Number | CAB530 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 3.55mOhm @ 530A, 15V |
| Supplier Device Package | Module |
| Gate Charge (Qg) (Max) @ Vgs | 1362nC @ 4V |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) |
| Input Capacitance (Ciss) (Max) @ Vds | 39600pF @ 800V |
| Current - Continuous Drain (Id) @ 25°C | 530A |
