Step1: Product
Weidmüller 2618030000
Images are for reference only
Manufacturer
Manufacturer No
2618030000
Availability
In Stock
Packaging
Box
Description
RELAY GEN PURPOSE SPDT 6A 120V
Detailed Description
General Purpose Relay SPDT (1 Form C) 120VAC Coil DIN Rail
Datasheet
Payment
Delivery
Mfr
Weidmüller
Grade
-
Series
TERMSERIES
Features
Lighted Indicator, RC Circuit, Socket Included
Coil Type
Non Latching
Packaging
Box
Relay Type
General Purpose
Seal Rating
-
Coil Current
7 mA
Coil Voltage
120VAC
Contact Form
SPDT (1 Form C)
Operate Time
15 ms
Release Time
50 ms
Mounting Type
DIN Rail
Qualification
-
Approval Agency
CE, cULus, EAC
Coil Insulation
-
Coil Resistance
17.1 kOhms
Contact Material
Silver Nickel (AgNi), Gold (Au)
Switching Voltage
250VAC, 250VDC - Max
Termination Style
Spring Terminal
Base Product Number
261803
Load - Max Switching
-
Must Operate Voltage
88 VAC
Must Release Voltage
43 VAC
Operating Temperature
-40°C ~ 60°C
Contact Rating (Current)
6 A
| Attribute | Value |
|---|---|
| Mfr | Weidmüller |
| Grade | - |
| Series | TERMSERIES |
| Features | Lighted Indicator, RC Circuit, Socket Included |
| Coil Type | Non Latching |
| Packaging | Box |
| Relay Type | General Purpose |
| Seal Rating | - |
| Coil Current | 7 mA |
| Coil Voltage | 120VAC |
| Contact Form | SPDT (1 Form C) |
| Operate Time | 15 ms |
| Release Time | 50 ms |
| Mounting Type | DIN Rail |
| Qualification | - |
| Approval Agency | CE, cULus, EAC |
| Coil Insulation | - |
| Coil Resistance | 17.1 kOhms |
| Contact Material | Silver Nickel (AgNi), Gold (Au) |
| Switching Voltage | 250VAC, 250VDC - Max |
| Termination Style | Spring Terminal |
| Base Product Number | 261803 |
| Load - Max Switching | - |
| Must Operate Voltage | 88 VAC |
| Must Release Voltage | 43 VAC |
| Operating Temperature | -40°C ~ 60°C |
| Contact Rating (Current) | 6 A |
