Step1: Product
TT Electronics/Power Partners Inc. PAA30B-10
Images are for reference only
Manufacturer
Manufacturer No
PAA30B-10
Availability
In Stock
Package
5-DIP Module, 4 Leads
Packaging
Box
Description
AC/DC CONVERTER 5.1V 23W
Detailed Description
Enclosed AC DC Converters 1 Output 5.1V 4.6A 90 ~ 305 VAC, 127 ~ 430 VDC Input
Datasheet
Payment
Delivery
Type
Enclosed
Series
PAA30B (23.46W)
Weight
-
Features
Universal Input
Packaging
Box
Efficiency
84%
Applications
Household Appliances, ITE (Commercial)
Manufacturer
TT Electronics/Power Partners Inc.
Mounting Type
Through Hole
Power (Watts)
23 W
Package / Case
5-DIP Module, 4 Leads
Approval Agency
CB, CE, cURus
Line Regulation
±1%
Load Regulation
±3%
Standard Number
60335-1; 60950-1; 62368-1
Voltage - Input
90 ~ 305 VAC, 127 ~ 430 VDC
Size / Dimension
2.53" L x 1.78" W x 0.85" H (64.2mm x 45.1mm x 21.7mm)
Number of Outputs
1
Voltage - Output 1
5.1V
Voltage - Output 2
-
Voltage - Output 3
-
Voltage - Output 4
-
Operating Temperature
-40°C ~ 70°C (With Derating)
Current - Output (Max)
4.6A
| Attribute | Value |
|---|---|
| Type | Enclosed |
| Series | PAA30B (23.46W) |
| Weight | - |
| Features | Universal Input |
| Packaging | Box |
| Efficiency | 84% |
| Applications | Household Appliances, ITE (Commercial) |
| Manufacturer | TT Electronics/Power Partners Inc. |
| Mounting Type | Through Hole |
| Power (Watts) | 23 W |
| Package / Case | 5-DIP Module, 4 Leads |
| Approval Agency | CB, CE, cURus |
| Line Regulation | ±1% |
| Load Regulation | ±3% |
| Standard Number | 60335-1; 60950-1; 62368-1 |
| Voltage - Input | 90 ~ 305 VAC, 127 ~ 430 VDC |
| Size / Dimension | 2.53" L x 1.78" W x 0.85" H (64.2mm x 45.1mm x 21.7mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 5.1V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Current - Output (Max) | 4.6A |
