TT Electronics/Power Partners Inc. PAA10-10
Images are for reference only
Manufacturer
Manufacturer No
PAA10-10
Availability
In Stock
Package
5-SIP Module
Packaging
Tube
Description
AC/DC CONVERTER 5V 10W
Detailed Description
Enclosed AC DC Converters 1 Output 5V 2A 90 ~ 305 VAC, 127 ~ 430 VDC Input
Datasheet
Payment
Delivery
Type
Enclosed
Series
PAA10 (10W)
Weight
-
Features
Universal Input
Packaging
Tube
Efficiency
81%
Applications
Household Appliances, ITE (Commercial)
Manufacturer
TT Electronics/Power Partners Inc.
Mounting Type
Through Hole
Power (Watts)
10 W
Package / Case
5-SIP Module
Approval Agency
CB, CE, cURus
Line Regulation
±0.2%
Load Regulation
±1%
Voltage - Input
90 ~ 305 VAC, 127 ~ 430 VDC
Size / Dimension
1.46" L x 1.08" W x 0.79" H (37.0mm x 27.5mm x 20.0mm)
Number of Outputs
1
Voltage - Output 1
5V
Voltage - Output 2
-
Voltage - Output 3
-
Voltage - Output 4
-
Base Product Number
PAA10
Operating Temperature
-40°C ~ 70°C (With Derating)
Current - Output (Max)
2A
| Attribute | Value |
|---|---|
| Type | Enclosed |
| Series | PAA10 (10W) |
| Weight | - |
| Features | Universal Input |
| Packaging | Tube |
| Efficiency | 81% |
| Applications | Household Appliances, ITE (Commercial) |
| Manufacturer | TT Electronics/Power Partners Inc. |
| Mounting Type | Through Hole |
| Power (Watts) | 10 W |
| Package / Case | 5-SIP Module |
| Approval Agency | CB, CE, cURus |
| Line Regulation | ±0.2% |
| Load Regulation | ±1% |
| Voltage - Input | 90 ~ 305 VAC, 127 ~ 430 VDC |
| Size / Dimension | 1.46" L x 1.08" W x 0.79" H (37.0mm x 27.5mm x 20.0mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Base Product Number | PAA10 |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Current - Output (Max) | 2A |
