Step1: Product
The Antenna Company AC94541-01N
Images are for reference only
Manufacturer
Manufacturer No
AC94541-01N
Packaging
Box
Description
ANT 410-470MHZ 5G 4G LTE DOME
Detailed Description
RF ANTENNA 4G, 5G, Cat-M1, CDMA, Cellular, GSM, LTE, LTE-M, NB-IoT, UMTS Dome N Type Female Bracket Mount
Datasheet
Payment
Delivery
Gain
-0.2dBi, 2dBi, 4.7dBi, 4.7dBi, 3.5dBi, 3dBi, 3dBi, 5dBi, 3.1dBi
VSWR
6, 1.8, 2.1, 2.5, 3.8, 3.6, 2, 2.4, 6.9
Grade
-
Series
-
Features
-
Packaging
Box
Power - Max
45 W
Return Loss
-2.9dB, -10.9dB, -9dB, -7.4dB, -4.7dB, -4.9dB, -9.5dB, -7.7dB, -2.5dB
Termination
N Type Female
Antenna Type
Dome
Applications
4G, 5G, Cat-M1, CDMA, Cellular, GSM, LTE, LTE-M, NB-IoT, UMTS
Height (Max)
10.039" (255.00mm)
Manufacturer
The Antenna Company
Mounting Type
Bracket Mount
Qualification
-
Frequency Group
Wide Band
Frequency Range
410MHz ~ 430MHz, 450MHz ~ 470MHz, 617MHz ~ 698MHz, 698MHz ~ 803MHz, 791MHz ~ 894MHz, 832MHz ~ 1.518GHz, 1.525GHz ~ 1.661GHz, 1.695GHz ~ 2.2GHz, 2.3GHz ~ 2.69GHz
Number of Bands
9
Ingress Protection
IP67
RF Family/Standard
Cellular
Base Product Number
AC94541
Frequency (Center/Band)
410MHz, 450MHz, 600MHz, 700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz
| Attribute | Value |
|---|---|
| Gain | -0.2dBi, 2dBi, 4.7dBi, 4.7dBi, 3.5dBi, 3dBi, 3dBi, 5dBi, 3.1dBi |
| VSWR | 6, 1.8, 2.1, 2.5, 3.8, 3.6, 2, 2.4, 6.9 |
| Grade | - |
| Series | - |
| Features | - |
| Packaging | Box |
| Power - Max | 45 W |
| Return Loss | -2.9dB, -10.9dB, -9dB, -7.4dB, -4.7dB, -4.9dB, -9.5dB, -7.7dB, -2.5dB |
| Termination | N Type Female |
| Antenna Type | Dome |
| Applications | 4G, 5G, Cat-M1, CDMA, Cellular, GSM, LTE, LTE-M, NB-IoT, UMTS |
| Height (Max) | 10.039" (255.00mm) |
| Manufacturer | The Antenna Company |
| Mounting Type | Bracket Mount |
| Qualification | - |
| Frequency Group | Wide Band |
| Frequency Range | 410MHz ~ 430MHz, 450MHz ~ 470MHz, 617MHz ~ 698MHz, 698MHz ~ 803MHz, 791MHz ~ 894MHz, 832MHz ~ 1.518GHz, 1.525GHz ~ 1.661GHz, 1.695GHz ~ 2.2GHz, 2.3GHz ~ 2.69GHz |
| Number of Bands | 9 |
| Ingress Protection | IP67 |
| RF Family/Standard | Cellular |
| Base Product Number | AC94541 |
| Frequency (Center/Band) | 410MHz, 450MHz, 600MHz, 700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz |
