Texas Instruments CSD87381P
Images are for reference only
Manufacturer
Manufacturer No
CSD87381P
Date Code
21+
Quantity
20,000
Availability
In Stock
Package
5-LGA
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
MOSFET 2N-CH 30V 15A 5PTAB
Detailed Description
Mosfet Array 30V 15A 4W Surface Mount 5-PTAB (3x2.5)
Datasheet
Payment
Delivery
Series
NexFET™
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
MOSFET (Metal Oxide)
FET Feature
Logic Level Gate
Power - Max
4W
Manufacturer
Texas Instruments
Configuration
2 N-Channel (Half Bridge)
Mounting Type
Surface Mount
Package / Case
5-LGA
Vgs(th) (Max) @ Id
1.9V @ 250µA
Base Product Number
CSD87381
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
16.3mOhm @ 8A, 8V
Supplier Device Package
5-PTAB (3x2.5)
Gate Charge (Qg) (Max) @ Vgs
5nC @ 4.5V
Drain to Source Voltage (Vdss)
30V
Input Capacitance (Ciss) (Max) @ Vds
564pF @ 15V
Current - Continuous Drain (Id) @ 25°C
15A
| Attribute | Value |
|---|---|
| Series | NexFET™ |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | Logic Level Gate |
| Power - Max | 4W |
| Manufacturer | Texas Instruments |
| Configuration | 2 N-Channel (Half Bridge) |
| Mounting Type | Surface Mount |
| Package / Case | 5-LGA |
| Vgs(th) (Max) @ Id | 1.9V @ 250µA |
| Base Product Number | CSD87381 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 16.3mOhm @ 8A, 8V |
| Supplier Device Package | 5-PTAB (3x2.5) |
| Gate Charge (Qg) (Max) @ Vgs | 5nC @ 4.5V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 564pF @ 15V |
| Current - Continuous Drain (Id) @ 25°C | 15A |
