Step1: Product
Tensility International Corp 50-00056
Images are for reference only
Manufacturer
Manufacturer No
50-00056
Availability
In Stock
Packaging
Bulk
Description
CONN PWR PLUG 1.35X3.5MM SOLDER
Detailed Description
Power Barrel Connector Plug 1.35mm ID (0.053"), 3.50mm OD (0.138") Free Hanging (In-Line)
Datasheet
Payment
Delivery
Gender
Female
Series
-
Features
-
Includes
-
Packaging
Bulk
Shielding
Unshielded
Body Color
Silver
Termination
Solder Eyelet(s)
Thread Size
-
Manufacturer
Tensility International Corp
Body Material
-
Mounting Type
Free Hanging (In-Line)
Connector Type
Plug
Actual Diameter
0.053" (1.35mm ID), 0.138" (3.50mm OD)
Voltage - Rated
20VDC
Contact Material
Phosphor Bronze
Housing Material
Brass
Insulation Color
-
Mounting Feature
-
Ingress Protection
-
Internal Switch(s)
Does Not Contain Switch
Mating Length/Depth
-
Current Rating (Amps)
4 A
Operating Temperature
-25°C ~ 70°C
Contact Material - Plating
Nickel
Material Flammability Rating
-
Number of Positions/Contacts
2 Conductors, 2 Contacts
Industry Recognized Mating Diameter
1.35mm ID (0.053"), 3.50mm OD (0.138")
| Attribute | Value |
|---|---|
| Gender | Female |
| Series | - |
| Features | - |
| Includes | - |
| Packaging | Bulk |
| Shielding | Unshielded |
| Body Color | Silver |
| Termination | Solder Eyelet(s) |
| Thread Size | - |
| Manufacturer | Tensility International Corp |
| Body Material | - |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug |
| Actual Diameter | 0.053" (1.35mm ID), 0.138" (3.50mm OD) |
| Voltage - Rated | 20VDC |
| Contact Material | Phosphor Bronze |
| Housing Material | Brass |
| Insulation Color | - |
| Mounting Feature | - |
| Ingress Protection | - |
| Internal Switch(s) | Does Not Contain Switch |
| Mating Length/Depth | - |
| Current Rating (Amps) | 4 A |
| Operating Temperature | -25°C ~ 70°C |
| Contact Material - Plating | Nickel |
| Material Flammability Rating | - |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts |
| Industry Recognized Mating Diameter | 1.35mm ID (0.053"), 3.50mm OD (0.138") |
