Step1: Product
TE Connectivity 5415025-1
Images are for reference only
Manufacturer
Manufacturer No
5415025-1
Quantity
6
Availability
In Stock
Packaging
Tray
Description
Conn BNC RA JCK PCB DECOUPLER
Detailed Description
BNC Connector Jack, Female Socket 50 Ohms Panel Mount, Through Hole, Right Angle Solder
Datasheet
Payment
Delivery
Mfr
TE Connectivity
Series
*
Impedance
50 Ohms
Packaging
Tray
Body Finish
Tin
Body Material
Zinc
Housing Color
Silver
Mating Cycles
500
Mounting Type
Panel Mount, Through Hole, Right Angle
Connector Type
Jack, Female Socket
Fastening Type
Bayonet Lock
Voltage Rating
500 V
Connector Style
BNC
Frequency - Max
4 GHz
Number of Ports
1
Mounting Feature
Bulkhead - Front Side Nut
Shield Termination
Solder
Contact Termination
Solder
Dielectric Material
Polytetrafluoroethylene (PTFE), Polymethylpentene (PMP)
Operating Temperature
-55°C ~ 85°C
Center Contact Plating
Gold
Center Contact Material
Phosphor Bronze
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity |
| Series | * |
| Impedance | 50 Ohms |
| Packaging | Tray |
| Body Finish | Tin |
| Body Material | Zinc |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Panel Mount, Through Hole, Right Angle |
| Connector Type | Jack, Female Socket |
| Fastening Type | Bayonet Lock |
| Voltage Rating | 500 V |
| Connector Style | BNC |
| Frequency - Max | 4 GHz |
| Number of Ports | 1 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Shield Termination | Solder |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE), Polymethylpentene (PMP) |
| Operating Temperature | -55°C ~ 85°C |
| Center Contact Plating | Gold |
| Center Contact Material | Phosphor Bronze |
