Step1: Product
TE Connectivity Potter & Brumfield Relays 1415068-1
Images are for reference only
Manufacturer
Manufacturer No
1415068-1
Availability
In Stock
Packaging
Tube
Description
V23092-A1005-A802
Detailed Description
General Purpose Relay SPST-NO (1 Form A) 5VDC Coil Through Hole
Datasheet
Payment
Delivery
Mfr
TE Connectivity Potter & Brumfield Relays
Grade
-
Series
V23092, AXICOM
Features
-
Coil Type
Non Latching
Packaging
Tube
Relay Type
General Purpose
Seal Rating
-
Coil Current
34 mA
Coil Voltage
5VDC
Contact Form
SPST-NO (1 Form A)
Operate Time
12 ms
Release Time
5 ms
Mounting Type
Through Hole
Qualification
-
Approval Agency
cURus, VDE
Coil Insulation
-
Coil Resistance
147 Ohms
Contact Material
Silver Nickel (AgNi)
Switching Voltage
400VAC - Max
Termination Style
PC Pin
Base Product Number
V23092
Load - Max Switching
2400VA
Must Operate Voltage
3.5 VDC
Must Release Voltage
0.25 VDC
Operating Temperature
-40°C ~ 85°C
Contact Rating (Current)
6 A
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Grade | - |
| Series | V23092, AXICOM |
| Features | - |
| Coil Type | Non Latching |
| Packaging | Tube |
| Relay Type | General Purpose |
| Seal Rating | - |
| Coil Current | 34 mA |
| Coil Voltage | 5VDC |
| Contact Form | SPST-NO (1 Form A) |
| Operate Time | 12 ms |
| Release Time | 5 ms |
| Mounting Type | Through Hole |
| Qualification | - |
| Approval Agency | cURus, VDE |
| Coil Insulation | - |
| Coil Resistance | 147 Ohms |
| Contact Material | Silver Nickel (AgNi) |
| Switching Voltage | 400VAC - Max |
| Termination Style | PC Pin |
| Base Product Number | V23092 |
| Load - Max Switching | 2400VA |
| Must Operate Voltage | 3.5 VDC |
| Must Release Voltage | 0.25 VDC |
| Operating Temperature | -40°C ~ 85°C |
| Contact Rating (Current) | 6 A |
