Step1: Product
RDI, Inc. RSJ-500-NL
Images are for reference only
Manufacturer
Manufacturer No
RSJ-500-NL
Availability
In Stock
Packaging
Tray
Description
3.5MM STEREO JACK
Detailed Description
3.20mm ID, 9.00mm OD (RCA) Phone Jack Stereo (3 Conductor, TRS) Connector Kinked Pin, Solder
Datasheet
Payment
Delivery
Mfr
RDI, Inc.
Gender
Female
Series
-
Features
-
Includes
-
Packaging
Tray
Shielding
Unshielded
Body Color
-
Termination
Kinked Pin, Solder
Thread Size
M6
Signal Lines
Stereo (3 Conductor, TRS)
Body Material
-
Cable Opening
-
Mounting Type
Through Hole, Right Angle
Connector Type
Phone Jack
Actual Diameter
-
Panel Hole Size
-
Voltage - Rated
16VDC
Contact Material
-
Housing Material
Polybutylene Terephthalate (PBT)
Insulation Color
-
Internal Switch(s)
Two Switches
Mating Length/Depth
0.551" (14.00mm)
Operating Temperature
-25°C ~ 100°C
Contact Material - Plating
-
Number of Positions/Contacts
3 Conductors, 5 Contacts
Industry Recognized Mating Diameter
3.20mm ID, 9.00mm OD (RCA)
| Attribute | Value |
|---|---|
| Mfr | RDI, Inc. |
| Gender | Female |
| Series | - |
| Features | - |
| Includes | - |
| Packaging | Tray |
| Shielding | Unshielded |
| Body Color | - |
| Termination | Kinked Pin, Solder |
| Thread Size | M6 |
| Signal Lines | Stereo (3 Conductor, TRS) |
| Body Material | - |
| Cable Opening | - |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Phone Jack |
| Actual Diameter | - |
| Panel Hole Size | - |
| Voltage - Rated | 16VDC |
| Contact Material | - |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Insulation Color | - |
| Internal Switch(s) | Two Switches |
| Mating Length/Depth | 0.551" (14.00mm) |
| Operating Temperature | -25°C ~ 100°C |
| Contact Material - Plating | - |
| Number of Positions/Contacts | 3 Conductors, 5 Contacts |
| Industry Recognized Mating Diameter | 3.20mm ID, 9.00mm OD (RCA) |
