NXP USA Inc. MC10XS4200CFKR2
Images are for reference only
Manufacturer
Manufacturer No
MC10XS4200CFKR2
Package
23-PowerQFN
Packaging
Tape & Reel (TR)
Description
HIGH-SIDE SWITCH, 24V, DUAL 10MO
Detailed Description
Power Switch/Driver 1:1 N-Channel 6A 23-PQFN (12x12)
Datasheet
Payment
Delivery
Mfr
NXP USA Inc.
Series
-
Features
Internal PWM, Slew Rate Controlled, Watchdog Timer
Interface
SPI
Packaging
Tape & Reel (TR)
Input Type
CMOS
Output Type
N-Channel
Switch Type
General Purpose
Rds On (Typ)
10mOhm (Max)
Mounting Type
Surface Mount
Package / Case
23-PowerQFN
Voltage - Load
8V ~ 36V
Fault Protection
Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO
Number of Outputs
2
Output Configuration
High Side
Ratio - Input:Output
1:1
Operating Temperature
-40°C ~ 125°C (TA)
Current - Output (Max)
6A
Supplier Device Package
23-PQFN (12x12)
Voltage - Supply (Vcc/Vdd)
3V ~ 5.5V
| Attribute | Value |
|---|---|
| Mfr | NXP USA Inc. |
| Series | - |
| Features | Internal PWM, Slew Rate Controlled, Watchdog Timer |
| Interface | SPI |
| Packaging | Tape & Reel (TR) |
| Input Type | CMOS |
| Output Type | N-Channel |
| Switch Type | General Purpose |
| Rds On (Typ) | 10mOhm (Max) |
| Mounting Type | Surface Mount |
| Package / Case | 23-PowerQFN |
| Voltage - Load | 8V ~ 36V |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO |
| Number of Outputs | 2 |
| Output Configuration | High Side |
| Ratio - Input:Output | 1:1 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Current - Output (Max) | 6A |
| Supplier Device Package | 23-PQFN (12x12) |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
