NXP USA Inc. MC40XS6500DEK
Images are for reference only
Manufacturer
Manufacturer No
MC40XS6500DEK
Quantity
15
Availability
In Stock
Package
32-SSOP (0.295", 7.50mm Width) Exposed Pad
Packaging
Tube
Description
LIGHTING ESWITCH PENTA 40MOHM
Detailed Description
Power Switch/Driver 1:6 N-Channel 3.9A 32-HSOP
Datasheet
Payment
Delivery
Mfr
NXP USA Inc.
Series
-
Features
Internal PWM, Slew Rate Controlled, Status Flag
Interface
PWM, SPI
Packaging
Tube
Input Type
Non-Inverting
Output Type
N-Channel
Switch Type
General Purpose
Rds On (Typ)
40mOhm
Mounting Type
Surface Mount
Package / Case
32-SSOP (0.295", 7.50mm Width) Exposed Pad
Voltage - Load
7V ~ 18V
Fault Protection
Current Limiting (Adjustable), Open Load Detect, Over Temperature, Over Voltage, Reverse Current, UVLO
Number of Outputs
6
Output Configuration
High Side
Ratio - Input:Output
1:6
Operating Temperature
-40°C ~ 125°C (TA)
Current - Output (Max)
3.9A
Supplier Device Package
32-HSOP
Voltage - Supply (Vcc/Vdd)
4.5V ~ 5.5V
| Attribute | Value |
|---|---|
| Mfr | NXP USA Inc. |
| Series | - |
| Features | Internal PWM, Slew Rate Controlled, Status Flag |
| Interface | PWM, SPI |
| Packaging | Tube |
| Input Type | Non-Inverting |
| Output Type | N-Channel |
| Switch Type | General Purpose |
| Rds On (Typ) | 40mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 32-SSOP (0.295", 7.50mm Width) Exposed Pad |
| Voltage - Load | 7V ~ 18V |
| Fault Protection | Current Limiting (Adjustable), Open Load Detect, Over Temperature, Over Voltage, Reverse Current, UVLO |
| Number of Outputs | 6 |
| Output Configuration | High Side |
| Ratio - Input:Output | 1:6 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Current - Output (Max) | 3.9A |
| Supplier Device Package | 32-HSOP |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
