Step1: Product
Nexperia USA Inc. PMGD280UN,115
Images are for reference only
Manufacturer
Manufacturer No
PMGD280UN,115
Quantity
5,425
Availability
In Stock
Package
6-TSSOP, SC-88, SOT-363
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
MOSFET 2N-CH 20V 0.87A 6TSSOP
Detailed Description
Mosfet Array 20V 870mA 400mW Surface Mount 6-TSSOP
Datasheet
Payment
Delivery
Series
TrenchMOS™
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
MOSFET (Metal Oxide)
FET Feature
Logic Level Gate
Power - Max
400mW
Manufacturer
Nexperia USA Inc.
Configuration
2 N-Channel (Dual)
Mounting Type
Surface Mount
Package / Case
6-TSSOP, SC-88, SOT-363
Vgs(th) (Max) @ Id
1V @ 250µA
Base Product Number
PMGD280
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
340mOhm @ 200mA, 4.5V
Supplier Device Package
6-TSSOP
Gate Charge (Qg) (Max) @ Vgs
0.89nC @ 4.5V
Drain to Source Voltage (Vdss)
20V
Input Capacitance (Ciss) (Max) @ Vds
45pF @ 20V
Current - Continuous Drain (Id) @ 25°C
870mA
| Attribute | Value |
|---|---|
| Series | TrenchMOS™ |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | Logic Level Gate |
| Power - Max | 400mW |
| Manufacturer | Nexperia USA Inc. |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Base Product Number | PMGD280 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 340mOhm @ 200mA, 4.5V |
| Supplier Device Package | 6-TSSOP |
| Gate Charge (Qg) (Max) @ Vgs | 0.89nC @ 4.5V |
| Drain to Source Voltage (Vdss) | 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 45pF @ 20V |
| Current - Continuous Drain (Id) @ 25°C | 870mA |
