Step1: Product
Molex 2069940100
Images are for reference only
Manufacturer
Manufacturer No
2069940100
Quantity
170
Availability
In Stock
Packaging
Bulk
Description
RF ANT 2.4GHZ/5GHZ PCB TRACE ADH
Detailed Description
RF ANTENNA Bluetooth, WLAN, Zigbee™ PCB Trace U.FL (UMCC), I-PEX MHF1 Adhesive
Datasheet
Payment
Delivery
Gain
3.6dBi
VSWR
-
Series
-
Features
Cable - 100mm
Packaging
Bulk
Return Loss
-5dB, -10dB
Termination
U.FL (UMCC), I-PEX MHF1
Antenna Type
PCB Trace
Applications
Bluetooth, WLAN, Zigbee™
Height (Max)
0.006" (0.15mm)
Manufacturer
Molex
Mounting Type
Adhesive
Frequency Group
UHF (2GHz ~ 3GHz), SHF (f > 4GHz)
Frequency Range
-
Number of Bands
2
Ingress Protection
-
RF Family/Standard
802.15.4, Bluetooth, WiFi
Base Product Number
206994
Frequency (Center/Band)
2.4GHz, 5GHz
| Attribute | Value |
|---|---|
| Gain | 3.6dBi |
| VSWR | - |
| Series | - |
| Features | Cable - 100mm |
| Packaging | Bulk |
| Return Loss | -5dB, -10dB |
| Termination | U.FL (UMCC), I-PEX MHF1 |
| Antenna Type | PCB Trace |
| Applications | Bluetooth, WLAN, Zigbee™ |
| Height (Max) | 0.006" (0.15mm) |
| Manufacturer | Molex |
| Mounting Type | Adhesive |
| Frequency Group | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) |
| Frequency Range | - |
| Number of Bands | 2 |
| Ingress Protection | - |
| RF Family/Standard | 802.15.4, Bluetooth, WiFi |
| Base Product Number | 206994 |
| Frequency (Center/Band) | 2.4GHz, 5GHz |
