Step1: Product
Lumex Opto/Components Inc. SMD-LX1818RGBDWCTR
Images are for reference only
Manufacturer
Manufacturer No
SMD-LX1818RGBDWCTR
Package
6-SMD, No Lead
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
LED RGB 1.8X1.8X0.65MM SMD
Detailed Description
Red, Green, Blue (RGB) LED Indication - Discrete 5V Red, 5V Green, 5V Blue 6-SMD, No Lead
Datasheet
Payment
Delivery
Mfr
Lumex Opto/Components Inc.
Color
Red, Green, Blue (RGB)
Grade
-
Series
-
Features
-
Lens Size
1.80mm
Packaging
Tape & Reel (TR); Cut Tape (CT)
Lens Color
Colorless
Lens Style
Square with Flat Top
Height (Max)
0.78mm
Configuration
-
Mounting Type
Surface Mount
Qualification
-
Viewing Angle
120°
Current - Test
-
Package / Case
6-SMD, No Lead
Size / Dimension
1.80mm L x 1.80mm W
Lens Transparency
Clear
Wavelength - Peak
630nm Red, 520nm Green, 470nm Blue
Millicandela Rating
425mcd Red, 1350mcd Green, 270mcd Blue
Wavelength - Dominant
-
Supplier Device Package
6-SMD
Voltage - Forward (Vf) (Typ)
5V Red, 5V Green, 5V Blue
| Attribute | Value |
|---|---|
| Mfr | Lumex Opto/Components Inc. |
| Color | Red, Green, Blue (RGB) |
| Grade | - |
| Series | - |
| Features | - |
| Lens Size | 1.80mm |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Lens Color | Colorless |
| Lens Style | Square with Flat Top |
| Height (Max) | 0.78mm |
| Configuration | - |
| Mounting Type | Surface Mount |
| Qualification | - |
| Viewing Angle | 120° |
| Current - Test | - |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 1.80mm L x 1.80mm W |
| Lens Transparency | Clear |
| Wavelength - Peak | 630nm Red, 520nm Green, 470nm Blue |
| Millicandela Rating | 425mcd Red, 1350mcd Green, 270mcd Blue |
| Wavelength - Dominant | - |
| Supplier Device Package | 6-SMD |
| Voltage - Forward (Vf) (Typ) | 5V Red, 5V Green, 5V Blue |
