Infineon Technologies BTM9010EPXUMA1
Images are for reference only
Manufacturer
Manufacturer No
BTM9010EPXUMA1
Quantity
84
Availability
In Stock
Package
14-TSSOP (0.154", 3.90mm Width) Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
BTM9010EPXUMA1
Detailed Description
Bipolar Motor Driver NMOS PWM PG-TSDSO-14
Datasheet
Payment
Delivery
Grade
Automotive
Series
MOTIX™
Function
Driver - Fully Integrated, Control and Power Stage
Interface
PWM
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
NMOS
Applications
General Purpose
Manufacturer
Infineon Technologies
Mounting Type
Surface Mount
Qualification
AEC-Q100
Package / Case
14-TSSOP (0.154", 3.90mm Width) Exposed Pad
Voltage - Load
4.5V ~ 40V
Step Resolution
-
Current - Output
5.2A
Voltage - Supply
4.5V ~ 40V
Motor Type - AC, DC
Brushed DC
Motor Type - Stepper
Bipolar
Output Configuration
Half Bridge (2)
Operating Temperature
-40°C ~ 150°C (TJ)
Supplier Device Package
PG-TSDSO-14
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Series | MOTIX™ |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Interface | PWM |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | NMOS |
| Applications | General Purpose |
| Manufacturer | Infineon Technologies |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Package / Case | 14-TSSOP (0.154", 3.90mm Width) Exposed Pad |
| Voltage - Load | 4.5V ~ 40V |
| Step Resolution | - |
| Current - Output | 5.2A |
| Voltage - Supply | 4.5V ~ 40V |
| Motor Type - AC, DC | Brushed DC |
| Motor Type - Stepper | Bipolar |
| Output Configuration | Half Bridge (2) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | PG-TSDSO-14 |
