Eaton - Electronics Division CTX20-3-R
Image is only for reference
| Attribute | Value |
|---|---|
| Height | 0.190" (4.83mm) |
| Series | OCTA-PAC® |
| Ratings | - |
| Packaging | Tape & Reel (TR) |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Manufacturer | Eaton - Electronics Division |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Number of Coils | 2 |
| Size / Dimension | 0.550" L x 0.550" W (13.97mm x 13.97mm) |
| Operating Temperature | -40°C ~ 85°C |
| Current Rating - Series | 750 mA |
| Current Rating - Parallel | 1.5 A |
| DC Resistance (DCR) - Series | 312mOhm Max |
| DC Resistance (DCR) - Parallel | 78mOhm Max |
| Inductance - Connected In Series | 80.74 µH |
| Inductance - Connected In Parallel | 20.18 µH |
