Diodes Incorporated DGD2136MS28-13
Image is only for reference
| Attribute | Value |
|---|---|
| Series | - |
| Gate Type | IGBT, MOSFET (N-Channel) |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Input Type | Inverting |
| Channel Type | 3-Phase |
| Manufacturer | Diodes Incorporated |
| Mounting Type | Surface Mount |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) |
| Voltage - Supply | 10V ~ 20V |
| Number of Drivers | 6 |
| Base Product Number | DGD2136 |
| DigiKey Programmable | Not Verified |
| Driven Configuration | Half-Bridge |
| Operating Temperature | 150°C (TJ) |
| Rise / Fall Time (Typ) | 90ns, 35ns |
| Supplier Device Package | 28-SO |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| High Side Voltage - Max (Bootstrap) | 600 V |
| Current - Peak Output (Source, Sink) | 200mA, 350mA |
