Step1: Product
CLIFF Electronic Components Ltd FCR681466
Images are for reference only
Manufacturer
Manufacturer No
FCR681466
Availability
In Stock
Packaging
Bulk
Description
DC-10LP DUAL SKT WHITE
Detailed Description
Power Barrel Connector Jack 2.10mm ID (0.083"), 2.50mm ID (0.098"), 6.30mm OD (0.248") Through Hole, Right Angle
Datasheet
Payment
Delivery
Gender
Male
Series
-
Features
-
Includes
-
Packaging
Bulk
Shielding
Unshielded
Body Color
White
Termination
Solder Eyelet(s)
Thread Size
-
Manufacturer
CLIFF Electronic Components Ltd
Body Material
Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type
Through Hole, Right Angle
Connector Type
Jack
Actual Diameter
-
Voltage - Rated
12VDC
Contact Material
Copper Alloy
Housing Material
Polybutylene Terephthalate (PBT), Glass Filled
Insulation Color
-
Mounting Feature
-
Ingress Protection
-
Internal Switch(s)
Single Switch, Normally Closed
Mating Length/Depth
-
Current Rating (Amps)
5 A
Operating Temperature
-
Contact Material - Plating
Tin
Material Flammability Rating
-
Number of Positions/Contacts
2 Conductors, 3 Contacts
Industry Recognized Mating Diameter
2.10mm ID (0.083"), 2.50mm ID (0.098"), 6.30mm OD (0.248")
| Attribute | Value |
|---|---|
| Gender | Male |
| Series | - |
| Features | - |
| Includes | - |
| Packaging | Bulk |
| Shielding | Unshielded |
| Body Color | White |
| Termination | Solder Eyelet(s) |
| Thread Size | - |
| Manufacturer | CLIFF Electronic Components Ltd |
| Body Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Jack |
| Actual Diameter | - |
| Voltage - Rated | 12VDC |
| Contact Material | Copper Alloy |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Insulation Color | - |
| Mounting Feature | - |
| Ingress Protection | - |
| Internal Switch(s) | Single Switch, Normally Closed |
| Mating Length/Depth | - |
| Current Rating (Amps) | 5 A |
| Operating Temperature | - |
| Contact Material - Plating | Tin |
| Material Flammability Rating | - |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Industry Recognized Mating Diameter | 2.10mm ID (0.083"), 2.50mm ID (0.098"), 6.30mm OD (0.248") |
