Step1: Product
Bivar Inc. SM0605RGB
Images are for reference only
Manufacturer
Manufacturer No
SM0605RGB
Date Code
1925
Quantity
10,684
Availability
In Stock
Package
0605 (1613 Metric)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
LED RGB CLEAR 0605 SMD
Detailed Description
Red, Green, Blue (RGB) 625nm Red, 525nm Green, 470nm Blue LED Indication - Discrete 2V Red, 3.1V Green, 2.9V Blue 0605 (1613 Metric)
Datasheet
Payment
Delivery
Mfr
Bivar Inc.
Color
Red, Green, Blue (RGB)
Series
-
Features
-
Lens Size
1.50mm x 1.00mm
Packaging
Tape & Reel (TR); Cut Tape (CT)
Lens Color
Colorless
Lens Style
Rectangle with Flat Top
Height (Max)
0.85mm
Configuration
Common Anode
Mounting Type
Surface Mount
Viewing Angle
120°
Current - Test
20mA Red, 20mA Green, 20mA Blue
Package / Case
0605 (1613 Metric)
Size / Dimension
1.60mm L x 1.50mm W
Lens Transparency
Clear
Wavelength - Peak
630nm Red, 523nm Green, 468nm Blue
Base Product Number
SM0605
Millicandela Rating
120mcd Red, 700mcd Green, 145mcd Blue
Wavelength - Dominant
625nm Red, 525nm Green, 470nm Blue
Supplier Device Package
0605
Voltage - Forward (Vf) (Typ)
2V Red, 3.1V Green, 2.9V Blue
| Attribute | Value |
|---|---|
| Mfr | Bivar Inc. |
| Color | Red, Green, Blue (RGB) |
| Series | - |
| Features | - |
| Lens Size | 1.50mm x 1.00mm |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Lens Color | Colorless |
| Lens Style | Rectangle with Flat Top |
| Height (Max) | 0.85mm |
| Configuration | Common Anode |
| Mounting Type | Surface Mount |
| Viewing Angle | 120° |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue |
| Package / Case | 0605 (1613 Metric) |
| Size / Dimension | 1.60mm L x 1.50mm W |
| Lens Transparency | Clear |
| Wavelength - Peak | 630nm Red, 523nm Green, 468nm Blue |
| Base Product Number | SM0605 |
| Millicandela Rating | 120mcd Red, 700mcd Green, 145mcd Blue |
| Wavelength - Dominant | 625nm Red, 525nm Green, 470nm Blue |
| Supplier Device Package | 0605 |
| Voltage - Forward (Vf) (Typ) | 2V Red, 3.1V Green, 2.9V Blue |
