Step1: Product
YIC ATIGGBL52580-100
Images are for reference only
Manufacturer
Manufacturer No
ATIGGBL52580-100
Packaging
Tray
Description
RF ANT GPS L1+L5/GLONASS/BEIDOU
Detailed Description
RF ANTENNA Beidou, GLONASS, GPS Ceramic Patch I-PEX MHF Surface Mount
Datasheet
Payment
Delivery
Gain
-2dBi, -2dBi, 0dBi, 2dBi
VSWR
2
Series
ATIGGBL5
Features
Cable - 100mm, LNA
Packaging
Tray
Return Loss
-
Termination
I-PEX MHF
Antenna Type
Ceramic Patch
Applications
Beidou, GLONASS, GPS
Height (Max)
0.315" (8.00mm)
Manufacturer
YIC
Mounting Type
Surface Mount
Frequency Group
UHF (1GHz ~ 2GHz)
Frequency Range
1.166GHz ~ 1.186GHz, 1.559GHz ~ 1.563GHz, 1.574GHz ~ 1.576GHz, 1.594GHz ~ 1.61GHz
Number of Bands
4
Ingress Protection
-
RF Family/Standard
Navigation
Frequency (Center/Band)
1.176GHz, 1.561GHz, 1.575GHz, 1.602GHz
| Attribute | Value |
|---|---|
| Gain | -2dBi, -2dBi, 0dBi, 2dBi |
| VSWR | 2 |
| Series | ATIGGBL5 |
| Features | Cable - 100mm, LNA |
| Packaging | Tray |
| Return Loss | - |
| Termination | I-PEX MHF |
| Antenna Type | Ceramic Patch |
| Applications | Beidou, GLONASS, GPS |
| Height (Max) | 0.315" (8.00mm) |
| Manufacturer | YIC |
| Mounting Type | Surface Mount |
| Frequency Group | UHF (1GHz ~ 2GHz) |
| Frequency Range | 1.166GHz ~ 1.186GHz, 1.559GHz ~ 1.563GHz, 1.574GHz ~ 1.576GHz, 1.594GHz ~ 1.61GHz |
| Number of Bands | 4 |
| Ingress Protection | - |
| RF Family/Standard | Navigation |
| Frequency (Center/Band) | 1.176GHz, 1.561GHz, 1.575GHz, 1.602GHz |
