Würth Elektronik 7448510091

Images are for reference only

Manufacturer

Würth Elektronik

Manufacturer No

7448510091

Package

Nonstandard

Packaging

Tape & Reel (TR); Cut Tape (CT)

Description

INDUCT ARRAY 2 COIL 91NH SMD

Detailed Description

Shielded 2 Coil Inductor Array 364 nH Inductance - Connected in Series 91 nH Inductance - Connected in Parallel 3.5mOhm Max DC Resistance (DCR) - Parallel 14.5 A Nonstandard

Datasheet

7448510091

Payment

Delivery

Height

0.453" (11.50mm)

Series

WE-DD

Ratings

-

Packaging

Tape & Reel (TR); Cut Tape (CT)

Shielding

Shielded

Tolerance

±20%

Manufacturer

Würth Elektronik

Mounting Type

Surface Mount

Package / Case

Nonstandard

Number of Coils

2

Size / Dimension

0.906" L x 0.728" W (23.00mm x 18.50mm)

Operating Temperature

-40°C ~ 125°C

Current Rating - Series

7.25 A

Current Rating - Parallel

14.5 A

Current Saturation - Series

60 A

DC Resistance (DCR) - Series

-

Current Saturation - Parallel

120 A

DC Resistance (DCR) - Parallel

3.5mOhm Max

Inductance - Connected In Series

364 nH

Inductance - Connected In Parallel

91 nH

Attribute	Value
Height	0.453" (11.50mm)
Series	WE-DD
Ratings	-
Packaging	Tape & Reel (TR); Cut Tape (CT)
Shielding	Shielded
Tolerance	±20%
Manufacturer	Würth Elektronik
Mounting Type	Surface Mount
Package / Case	Nonstandard
Number of Coils	2
Size / Dimension	0.906" L x 0.728" W (23.00mm x 18.50mm)
Operating Temperature	-40°C ~ 125°C
Current Rating - Series	7.25 A
Current Rating - Parallel	14.5 A
Current Saturation - Series	60 A
DC Resistance (DCR) - Series	-
Current Saturation - Parallel	120 A
DC Resistance (DCR) - Parallel	3.5mOhm Max
Inductance - Connected In Series	364 nH
Inductance - Connected In Parallel	91 nH
