Step1: Product
Vishay Dale Thin Film M55342H05B909ARWS
Images are for reference only
Manufacturer
Manufacturer No
M55342H05B909ARWS
Package
Nonstandard
Packaging
Tray
Description
RES SMD 909 OHM 0.1% 0.225W 2208
Detailed Description
909 Ohms ±0.1% 0.225W Chip Resistor Nonstandard Military, Non-Inductive Thin Film
Datasheet
Payment
Delivery
Mfr
Vishay Dale Thin Film
Series
Military, MIL-PRF-55342, RM2208
Features
Military, Non-Inductive
Packaging
Tray
Tolerance
±0.1%
Resistance
909 Ohms
Composition
Thin Film
Failure Rate
R (0.01%)
Power (Watts)
0.225W
Package / Case
Nonstandard
Size / Dimension
0.230" L x 0.075" W (5.84mm x 1.90mm)
Base Product Number
M55342
Height - Seated (Max)
0.033" (0.84mm)
Operating Temperature
-55°C ~ 150°C
Number of Terminations
2
Supplier Device Package
2208
Temperature Coefficient
±50ppm/°C
| Attribute | Value |
|---|---|
| Mfr | Vishay Dale Thin Film |
| Series | Military, MIL-PRF-55342, RM2208 |
| Features | Military, Non-Inductive |
| Packaging | Tray |
| Tolerance | ±0.1% |
| Resistance | 909 Ohms |
| Composition | Thin Film |
| Failure Rate | R (0.01%) |
| Power (Watts) | 0.225W |
| Package / Case | Nonstandard |
| Size / Dimension | 0.230" L x 0.075" W (5.84mm x 1.90mm) |
| Base Product Number | M55342 |
| Height - Seated (Max) | 0.033" (0.84mm) |
| Operating Temperature | -55°C ~ 150°C |
| Number of Terminations | 2 |
| Supplier Device Package | 2208 |
| Temperature Coefficient | ±50ppm/°C |
