Step1: Product
Vicor Corporation DCM3717S60E14G5TN0
Images are for reference only
Manufacturer
Manufacturer No
DCM3717S60E14G5TN0
Package
16-SMD Module
Packaging
Tray
Description
DC DC CONVERTER 12.2V 750W
Detailed Description
Non-Isolated PoL Module DC DC Converter 1 Output 12.2V 62.5A 40V - 60V Input
Datasheet
Payment
Delivery
Mfr
Vicor Corporation
Type
Non-Isolated PoL Module
Series
DCM™
Features
Adjustable Output
Packaging
Tray
Efficiency
96.80%
Applications
ITE (Commercial)
Mounting Type
Surface Mount
Power (Watts)
750 W
Package / Case
16-SMD Module
Approval Agency
CE
Control Features
-
Size / Dimension
1.45" L x 0.68" W x 0.29" H (36.7mm x 17.3mm x 7.4mm)
Number of Outputs
1
Voltage - Output 1
12.2V
Voltage - Output 2
-
Voltage - Output 3
-
Voltage - Output 4
-
Base Product Number
DCM3717
Operating Temperature
-20°C ~ 125°C
Voltage - Input (Max)
60V
Voltage - Input (Min)
40V
Current - Output (Max)
62.5A
Supplier Device Package
-
| Attribute | Value |
|---|---|
| Mfr | Vicor Corporation |
| Type | Non-Isolated PoL Module |
| Series | DCM™ |
| Features | Adjustable Output |
| Packaging | Tray |
| Efficiency | 96.80% |
| Applications | ITE (Commercial) |
| Mounting Type | Surface Mount |
| Power (Watts) | 750 W |
| Package / Case | 16-SMD Module |
| Approval Agency | CE |
| Control Features | - |
| Size / Dimension | 1.45" L x 0.68" W x 0.29" H (36.7mm x 17.3mm x 7.4mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 12.2V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Base Product Number | DCM3717 |
| Operating Temperature | -20°C ~ 125°C |
| Voltage - Input (Max) | 60V |
| Voltage - Input (Min) | 40V |
| Current - Output (Max) | 62.5A |
| Supplier Device Package | - |
