Venkel BAV16W-EVL

Images are for reference only

Manufacturer

Venkel

Manufacturer No

BAV16W-EVL

Package

SOD-123

Packaging

Tape & Reel (TR)

Description

DIODE STANDARD 75V 150MA

Detailed Description

Diode 75 V 150mA Surface Mount

Payment

Delivery

Mfr

Venkel

Speed

Small Signal =< 200mA (Io), Any Speed

Series

RSD

Packaging

Tape & Reel (TR)

Technology

Standard

Mounting Type

Surface Mount

Package / Case

SOD-123

Capacitance @ Vr, F

2pF @ 0V, 1MHz

Reverse Recovery Time (trr)

6 ns

Current - Reverse Leakage @ Vr

1 µA @ 75 V

Voltage - DC Reverse (Vr) (Max)

75 V

Current - Average Rectified (Io)

150mA

Operating Temperature - Junction

-55°C ~ 150°C

Voltage - Forward (Vf) (Max) @ If

855 mV @ 10 mA

Attribute	Value
Mfr	Venkel
Speed	Small Signal =< 200mA (Io), Any Speed
Series	RSD
Packaging	Tape & Reel (TR)
Technology	Standard
Mounting Type	Surface Mount
Package / Case	SOD-123
Capacitance @ Vr, F	2pF @ 0V, 1MHz
Reverse Recovery Time (trr)	6 ns
Current - Reverse Leakage @ Vr	1 µA @ 75 V
Voltage - DC Reverse (Vr) (Max)	75 V
Current - Average Rectified (Io)	150mA
Operating Temperature - Junction	-55°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If	855 mV @ 10 mA
