Step1: Product
TE Connectivity Potter & Brumfield Relays R10A-E1X6-V430
Images are for reference only
Manufacturer
Manufacturer No
R10A-E1X6-V430
Availability
In Stock
Packaging
Bulk
Description
RELAY DRY CIR
Detailed Description
General Purpose Relay 6PDT (6 Form C) 24VDC Coil Socketable
Datasheet
Payment
Delivery
Mfr
TE Connectivity Potter & Brumfield Relays
Grade
-
Series
R10A
Features
-
Coil Type
Non Latching
Packaging
Bulk
Relay Type
General Purpose
Seal Rating
-
Coil Current
55.8 mA
Coil Voltage
24VDC
Contact Form
6PDT (6 Form C)
Mounting Type
Socketable
Qualification
-
Approval Agency
-
Coil Insulation
-
Coil Resistance
430 Ohms
Contact Material
Silver Cadmium Oxide (AgCdO)
Switching Voltage
120VAC, 30VDC - Max
Termination Style
Plug In
Base Product Number
R10A-E1X6
Load - Max Switching
600VA, 150W
Must Operate Voltage
18 VDC
Must Release Voltage
-
Operating Temperature
-55°C ~ 75°C
Contact Rating (Current)
5 A
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Grade | - |
| Series | R10A |
| Features | - |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Seal Rating | - |
| Coil Current | 55.8 mA |
| Coil Voltage | 24VDC |
| Contact Form | 6PDT (6 Form C) |
| Mounting Type | Socketable |
| Qualification | - |
| Approval Agency | - |
| Coil Insulation | - |
| Coil Resistance | 430 Ohms |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Switching Voltage | 120VAC, 30VDC - Max |
| Termination Style | Plug In |
| Base Product Number | R10A-E1X6 |
| Load - Max Switching | 600VA, 150W |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | - |
| Operating Temperature | -55°C ~ 75°C |
| Contact Rating (Current) | 5 A |
