Step1: Product
TE Connectivity AMP Connectors LEV200A5ANA
Images are for reference only
Manufacturer
Manufacturer No
LEV200A5ANA
Quantity
4
Availability
In Stock
Packaging
Bulk
Description
INDUSTRIAL RELAYS 500A 24VDC 1 F
Detailed Description
Contactor SPST-NO (DM) (1 Form X) 500 A 24VDC Coil Chassis Mount
Datasheet
Payment
Delivery
Series
LEV200, KILOVAC
Features
Sealed - Hermetically
Packaging
Bulk
Coil Power
-
Coil Current
600 mA
Coil Voltage
24VDC
Contact Form
SPST-NO (DM) (1 Form X)
Manufacturer
TE Connectivity AMP Connectors
Operate Time
25 ms
Release Time
12 ms
Mounting Type
Chassis Mount
Coil Resistance
40Ohms
Contact Material
-
Switching Voltage
900VDC - Max
Termination Style
Stud, Wire Leads
Must Operate Voltage
19 VDC
Must Release Voltage
5 VDC
Operating Temperature
-40°C ~ 85°C
Contact Rating (Current)
500 A
| Attribute | Value |
|---|---|
| Series | LEV200, KILOVAC |
| Features | Sealed - Hermetically |
| Packaging | Bulk |
| Coil Power | - |
| Coil Current | 600 mA |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Manufacturer | TE Connectivity AMP Connectors |
| Operate Time | 25 ms |
| Release Time | 12 ms |
| Mounting Type | Chassis Mount |
| Coil Resistance | 40Ohms |
| Contact Material | - |
| Switching Voltage | 900VDC - Max |
| Termination Style | Stud, Wire Leads |
| Must Operate Voltage | 19 VDC |
| Must Release Voltage | 5 VDC |
| Operating Temperature | -40°C ~ 85°C |
| Contact Rating (Current) | 500 A |
