Step1: Product
TE Connectivity AMP Connectors 5645500-1
Images are for reference only
Manufacturer
Manufacturer No
5645500-1
Packaging
Bulk
Description
CONN PIN RCPT .037-.041 SOLDER
Detailed Description
Pin Receptacle Connector 0.037" ~ 0.041" (0.94mm ~ 1.04mm) No Tail Solder
Datasheet
Payment
Delivery
Series
4
Features
-
Packaging
Bulk
Tail Type
No Tail
Termination
Solder
Manufacturer
TE Connectivity AMP Connectors
Socket Depth
0.100" ~ 0.210" (2.54mm ~ 5.33mm)
Tail Diameter
-
Contact Finish
Gold
Board Thickness
-
Flange Diameter
0.089" (2.26mm)
Insertion Force
-
Contact Material
Beryllium Copper
Length - Overall
0.260" (6.60mm)
Pin Hole Diameter
-
Base Product Number
5645500
Accepts Pin Diameter
0.037" ~ 0.041" (0.94mm ~ 1.04mm)
Operating Temperature
-65°C ~ 126°C
Mounting Hole Diameter
0.069" ~ 0.075" (1.75mm ~ 1.91mm)
Accepts Square Pin Size
-
Contact Finish Thickness
30.0µin (0.76µm)
| Attribute | Value |
|---|---|
| Series | 4 |
| Features | - |
| Packaging | Bulk |
| Tail Type | No Tail |
| Termination | Solder |
| Manufacturer | TE Connectivity AMP Connectors |
| Socket Depth | 0.100" ~ 0.210" (2.54mm ~ 5.33mm) |
| Tail Diameter | - |
| Contact Finish | Gold |
| Board Thickness | - |
| Flange Diameter | 0.089" (2.26mm) |
| Insertion Force | - |
| Contact Material | Beryllium Copper |
| Length - Overall | 0.260" (6.60mm) |
| Pin Hole Diameter | - |
| Base Product Number | 5645500 |
| Accepts Pin Diameter | 0.037" ~ 0.041" (0.94mm ~ 1.04mm) |
| Operating Temperature | -65°C ~ 126°C |
| Mounting Hole Diameter | 0.069" ~ 0.075" (1.75mm ~ 1.91mm) |
| Accepts Square Pin Size | - |
| Contact Finish Thickness | 30.0µin (0.76µm) |
