Step1: Product
TE Connectivity AMP Connectors 1546234-1
Images are for reference only
Manufacturer
Manufacturer No
1546234-1
Packaging
Bulk
Description
TERM BLK 2POS GRAY
Detailed Description
2 Position Terminal Block Gray NEMA Open Construction 10.9mm
Datasheet
Payment
Delivery
Type
NEMA Open Construction
Length
1.231" (31.27mm)
Series
900, Buchanan
Features
-
Packaging
Bulk
Current - UL
30 A
Height (Max)
1.225" (31.12mm)
Manufacturer
TE Connectivity AMP Connectors
Voltage - UL
600 V
Housing Color
Gray
Mounting Type
Direct Mount
Number of Levels
1
Stripping Length
-
Terminal - Width
10.9mm
Termination Style
Tubular Clamp
Base Product Number
1546234
Number of Positions
2
Material - Insulation
Polyester
Operating Temperature
150°C
Wire Gauge or Range - AWG
10-22 AWG
Wire Gauge or Range - mm²
-
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Type | NEMA Open Construction |
| Length | 1.231" (31.27mm) |
| Series | 900, Buchanan |
| Features | - |
| Packaging | Bulk |
| Current - UL | 30 A |
| Height (Max) | 1.225" (31.12mm) |
| Manufacturer | TE Connectivity AMP Connectors |
| Voltage - UL | 600 V |
| Housing Color | Gray |
| Mounting Type | Direct Mount |
| Number of Levels | 1 |
| Stripping Length | - |
| Terminal - Width | 10.9mm |
| Termination Style | Tubular Clamp |
| Base Product Number | 1546234 |
| Number of Positions | 2 |
| Material - Insulation | Polyester |
| Operating Temperature | 150°C |
| Wire Gauge or Range - AWG | 10-22 AWG |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
