Step1: Product
TE Connectivity ALCOSWITCH Switches 436028-1
Images are for reference only
Manufacturer
Manufacturer No
436028-1
Packaging
Tray
Description
SWITCH ROTARY 24POS 125MA 115V
Detailed Description
Rotary Switch 24 Position BCD 125mA (AC) 115 VAC Panel Mount, Through Hole
Datasheet
Payment
Delivery
Series
3100
Features
-
Packaging
Tray
Index Stops
Continuous
Manufacturer
TE Connectivity ALCOSWITCH Switches
Actuator Type
Flatted (6.35mm Dia)
Mounting Type
Panel Mount, Through Hole
Angle of Throw
15°
Contact Finish
Gold
Contact Timing
Not Specified
Actuator Length
14.88mm
Number of Decks
1
Circuit per Deck
BCD
Contact Material
Phosphor Bronze
Termination Style
PC Pin
Depth Behind Panel
13.34mm
Base Product Number
436028
Number of Positions
24
Voltage Rating - AC
115 V
Current Rating (Amps)
125mA (AC)
Panel Cutout Dimensions
Circular - 9.58mm Dia
Number of Poles per Deck
-
| Attribute | Value |
|---|---|
| Series | 3100 |
| Features | - |
| Packaging | Tray |
| Index Stops | Continuous |
| Manufacturer | TE Connectivity ALCOSWITCH Switches |
| Actuator Type | Flatted (6.35mm Dia) |
| Mounting Type | Panel Mount, Through Hole |
| Angle of Throw | 15° |
| Contact Finish | Gold |
| Contact Timing | Not Specified |
| Actuator Length | 14.88mm |
| Number of Decks | 1 |
| Circuit per Deck | BCD |
| Contact Material | Phosphor Bronze |
| Termination Style | PC Pin |
| Depth Behind Panel | 13.34mm |
| Base Product Number | 436028 |
| Number of Positions | 24 |
| Voltage Rating - AC | 115 V |
| Current Rating (Amps) | 125mA (AC) |
| Panel Cutout Dimensions | Circular - 9.58mm Dia |
| Number of Poles per Deck | - |
