TE Connectivity ALCOSWITCH Switches 1571095-4
Images are for reference only
Manufacturer
Manufacturer No
1571095-4
Packaging
Bulk
Description
SWITCH ROCKER SPST 20A 125V
Detailed Description
Rocker Switch SPST 20A (AC) 125 V Panel Mount, Snap-In
Datasheet
Payment
Delivery
Mfr
TE Connectivity ALCOSWITCH Switches
Series
PRC
Circuit
SPST
Features
-
Packaging
Bulk
Actuator Type
Concave (Curved)
Mounting Type
Panel Mount, Snap-In
Approval Agency
-
Electrical Life
6,000 Cycles
Mechanical Life
100,000 Cycles
Switch Function
On-Off
Actuator Marking
No Marking
Termination Style
Solder Lug
Ingress Protection
IP66 - Dust Tight, Water Resistant
Base Product Number
1571095
Voltage Rating - AC
125 V
Color - Actuator/Cap
Black
Current Rating (Amps)
20A (AC)
Operating Temperature
-20°C ~ 85°C
Panel Cutout Dimensions
Rectangular - 36.60mm x 21.20mm
Illumination Type, Color
-
Illumination Voltage (Nominal)
-
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity ALCOSWITCH Switches |
| Series | PRC |
| Circuit | SPST |
| Features | - |
| Packaging | Bulk |
| Actuator Type | Concave (Curved) |
| Mounting Type | Panel Mount, Snap-In |
| Approval Agency | - |
| Electrical Life | 6,000 Cycles |
| Mechanical Life | 100,000 Cycles |
| Switch Function | On-Off |
| Actuator Marking | No Marking |
| Termination Style | Solder Lug |
| Ingress Protection | IP66 - Dust Tight, Water Resistant |
| Base Product Number | 1571095 |
| Voltage Rating - AC | 125 V |
| Color - Actuator/Cap | Black |
| Current Rating (Amps) | 20A (AC) |
| Operating Temperature | -20°C ~ 85°C |
| Panel Cutout Dimensions | Rectangular - 36.60mm x 21.20mm |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
