Step1: Product
TE Connectivity Aerospace, Defense and Marine 530780-3
Images are for reference only
Manufacturer
Manufacturer No
530780-3
Packaging
Bulk
Description
CONN RCPT 50POS 0.1 GOLD PCB
Detailed Description
50 Position Receptacle Connector 0.100" (2.54mm) Through Hole Gold
Datasheet
Payment
Delivery
Mfr
TE Connectivity Aerospace, Defense and Marine
Style
Board to Board
Series
Box
Features
Mating Guide
Packaging
Bulk
Termination
Wire Wrap
Applications
-
Contact Type
Female Socket
Contact Shape
Circular
Mounting Type
Through Hole
Connector Type
Receptacle
Fastening Type
Push-Pull
Number of Rows
2
Pitch - Mating
0.100" (2.54mm)
Voltage Rating
-
Contact Material
Beryllium Copper
Insulation Color
Blue
Insulation Height
0.400" (10.16mm)
Ingress Protection
-
Base Product Number
530780
Insulation Material
Diallyl Phthalate (DAP)
Number of Positions
50
Row Spacing - Mating
0.100" (2.54mm)
Contact Finish - Post
-
Contact Length - Post
0.565" (14.35mm)
Current Rating (Amps)
-
Operating Temperature
-
Mated Stacking Heights
-
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
-
Contact Finish Thickness - Post
-
Contact Finish Thickness - Mating
50.0µin (1.27µm)
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Aerospace, Defense and Marine |
| Style | Board to Board |
| Series | Box |
| Features | Mating Guide |
| Packaging | Bulk |
| Termination | Wire Wrap |
| Applications | - |
| Contact Type | Female Socket |
| Contact Shape | Circular |
| Mounting Type | Through Hole |
| Connector Type | Receptacle |
| Fastening Type | Push-Pull |
| Number of Rows | 2 |
| Pitch - Mating | 0.100" (2.54mm) |
| Voltage Rating | - |
| Contact Material | Beryllium Copper |
| Insulation Color | Blue |
| Insulation Height | 0.400" (10.16mm) |
| Ingress Protection | - |
| Base Product Number | 530780 |
| Insulation Material | Diallyl Phthalate (DAP) |
| Number of Positions | 50 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Contact Finish - Post | - |
| Contact Length - Post | 0.565" (14.35mm) |
| Current Rating (Amps) | - |
| Operating Temperature | - |
| Mated Stacking Heights | - |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | - |
| Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | 50.0µin (1.27µm) |
