Tamura MET-50
Series
MET
Weight
-
Packaging
Tray
Power Level
10mW Max @ 300Hz
Return Loss
-
Manufacturer
Tamura
Mounting Type
Through Hole
Insertion Loss
-
Approval Agency
-
Frequency Range
300Hz ~ 20kHz
Size / Dimension
0.409" L x 0.310" W (10.40mm x 7.87mm)
Transformer Type
Data/Voice Coupling
Termination Style
PC Pin
Frequency Response
±3dB
Voltage - Isolation
500VRMS @ 30 Seconds
Height - Seated (Max)
0.465" (11.80mm)
Operating Temperature
-20°C ~ 85°C
Impedance - Primary (Ohms)
10k
Impedance - Secondary (Ohms)
125
DC Resistance (DCR) - Primary
1.1kOhm
DC Resistance (DCR) - Secondary
28Ohm
Turns Ratio - Primary:Secondary
8.62:1
| Attribute | Value |
|---|---|
| Series | MET |
| Weight | - |
| Packaging | Tray |
| Power Level | 10mW Max @ 300Hz |
| Return Loss | - |
| Manufacturer | Tamura |
| Mounting Type | Through Hole |
| Insertion Loss | - |
| Approval Agency | - |
| Frequency Range | 300Hz ~ 20kHz |
| Size / Dimension | 0.409" L x 0.310" W (10.40mm x 7.87mm) |
| Transformer Type | Data/Voice Coupling |
| Termination Style | PC Pin |
| Frequency Response | ±3dB |
| Voltage - Isolation | 500VRMS @ 30 Seconds |
| Height - Seated (Max) | 0.465" (11.80mm) |
| Operating Temperature | -20°C ~ 85°C |
| Impedance - Primary (Ohms) | 10k |
| Impedance - Secondary (Ohms) | 125 |
| DC Resistance (DCR) - Primary | 1.1kOhm |
| DC Resistance (DCR) - Secondary | 28Ohm |
| Turns Ratio - Primary:Secondary | 8.62:1 |
