Step1: Product
Superworld Electronics (S) Pte. Ltd. STX106530612R5KT
Images are for reference only
Manufacturer
Manufacturer No
STX106530612R5KT
Packaging
Bulk
Description
3 COIL 1 LAYER 12.5UH, 11.5UH, 1
Detailed Description
3 Coil, 1 Layer 12.5µH, 11.5µH, 12.5µH Wireless Charging Coil Transmitter 80mOhm Max
Datasheet
Payment
Delivery
Type
3 Coil, 1 Layer
Series
STX
Function
Transmitter
Q @ Freq
-
Packaging
Bulk
Tolerance
±10%
Inductance
12.5µH, 11.5µH, 12.5µH
Manufacturer
Superworld Electronics (S) Pte. Ltd.
Size / Dimension
4.17" L x 2.09" W x 0.24" H (106.0mm x 53.0mm x 6.0mm)
DC Resistance (DCR)
80mOhm Max
Current Rating (Amps)
6.5A
Operating Temperature
-40°C ~ 85°C
Frequency - Self Resonant
-
Current - Saturation (Isat)
-
| Attribute | Value |
|---|---|
| Type | 3 Coil, 1 Layer |
| Series | STX |
| Function | Transmitter |
| Q @ Freq | - |
| Packaging | Bulk |
| Tolerance | ±10% |
| Inductance | 12.5µH, 11.5µH, 12.5µH |
| Manufacturer | Superworld Electronics (S) Pte. Ltd. |
| Size / Dimension | 4.17" L x 2.09" W x 0.24" H (106.0mm x 53.0mm x 6.0mm) |
| DC Resistance (DCR) | 80mOhm Max |
| Current Rating (Amps) | 6.5A |
| Operating Temperature | -40°C ~ 85°C |
| Frequency - Self Resonant | - |
| Current - Saturation (Isat) | - |
