STMicroelectronics STGD4H60DF

Images are for reference only

Manufacturer

STMicroelectronics

Manufacturer No

STGD4H60DF

Package

TO-252-3, DPAK (2 Leads + Tab), SC-63

Packaging

Tape & Reel (TR); Cut Tape (CT)

Description

IGBT TRENCH FS 600V 8A DPAK

Detailed Description

IGBT Trench Field Stop 600 V 8 A 75 W Surface Mount DPAK (TO-252) type C2

Datasheet

STGD4H60DF

Payment

Delivery

Series

H

IGBT Type

Trench Field Stop

Packaging

Tape & Reel (TR); Cut Tape (CT)

Input Type

Standard

Gate Charge

35 nC

Power - Max

75 W

Manufacturer

STMicroelectronics

Mounting Type

Surface Mount

Package / Case

TO-252-3, DPAK (2 Leads + Tab), SC-63

Test Condition

400V, 3A, 47Ohm, 15V

Switching Energy

68µJ (on), 45µJ (off)

Td (on/off) @ 25°C

35ns/121ns

Operating Temperature

-55°C ~ 175°C (TJ)

Supplier Device Package

DPAK (TO-252) type C2

Vce(on) (Max) @ Vge, Ic

1.95V @ 15V, 3A

Reverse Recovery Time (trr)

73 ns

Current - Collector (Ic) (Max)

8 A

Current - Collector Pulsed (Icm)

16 A

Voltage - Collector Emitter Breakdown (Max)

600 V

Attribute	Value
Series	H
IGBT Type	Trench Field Stop
Packaging	Tape & Reel (TR); Cut Tape (CT)
Input Type	Standard
Gate Charge	35 nC
Power - Max	75 W
Manufacturer	STMicroelectronics
Mounting Type	Surface Mount
Package / Case	TO-252-3, DPAK (2 Leads + Tab), SC-63
Test Condition	400V, 3A, 47Ohm, 15V
Switching Energy	68µJ (on), 45µJ (off)
Td (on/off) @ 25°C	35ns/121ns
Operating Temperature	-55°C ~ 175°C (TJ)
Supplier Device Package	DPAK (TO-252) type C2
Vce(on) (Max) @ Vge, Ic	1.95V @ 15V, 3A
Reverse Recovery Time (trr)	73 ns
Current - Collector (Ic) (Max)	8 A
Current - Collector Pulsed (Icm)	16 A
Voltage - Collector Emitter Breakdown (Max)	600 V
