Step1: Product
Sanyo SH2141-5541
Images are for reference only
Manufacturer
Manufacturer No
SH2141-5541
Packaging
Bulk
Description
STPR MTR BIPOLAR 6.3V 0.3A/PHASE
Detailed Description
Bipolar Stepper Motor Hybrid Frame Size 200.0 Step 300 mA 24VDC
Datasheet
Payment
Delivery
Mfr
Sanyo
Type
Hybrid
Series
SH
Weight
-
Accuracy
-
Features
-
Coil Type
Bipolar
Packaging
Bulk
Step Angle
1.8°
Rotor Inertia
0.58gcm²
Approval Agency
CE, cURus, TUV
Coil Resistance
21 Ohms
Voltage - Rated
24VDC
Diameter - Shaft
0.157" (4.00mm)
Size / Dimension
Square - 0.551" x 0.551" (14.00mm x 14.00mm)
Termination Style
Wire Leads
Steps per Revolution
200.0
Current Rating (Amps)
300 mA
Mounting Hole Spacing
0.453" (11.50mm)
Operating Temperature
-10°C ~ 50°C
Length - Shaft and Bearing
0.591" (15.00mm)
Torque - Holding (oz-in / mNm)
0.92 / 6.5
| Attribute | Value |
|---|---|
| Mfr | Sanyo |
| Type | Hybrid |
| Series | SH |
| Weight | - |
| Accuracy | - |
| Features | - |
| Coil Type | Bipolar |
| Packaging | Bulk |
| Step Angle | 1.8° |
| Rotor Inertia | 0.58gcm² |
| Approval Agency | CE, cURus, TUV |
| Coil Resistance | 21 Ohms |
| Voltage - Rated | 24VDC |
| Diameter - Shaft | 0.157" (4.00mm) |
| Size / Dimension | Square - 0.551" x 0.551" (14.00mm x 14.00mm) |
| Termination Style | Wire Leads |
| Steps per Revolution | 200.0 |
| Current Rating (Amps) | 300 mA |
| Mounting Hole Spacing | 0.453" (11.50mm) |
| Operating Temperature | -10°C ~ 50°C |
| Length - Shaft and Bearing | 0.591" (15.00mm) |
| Torque - Holding (oz-in / mNm) | 0.92 / 6.5 |
