ROHM Semiconductor BD6220F-E2
Images are for reference only
Manufacturer
Manufacturer No
BD6220F-E2
Quantity
2,648
Availability
In Stock
Package
8-SOIC (0.173", 4.40mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC HALF BRIDGE DRIVER 500MA 8SOP
Detailed Description
Half Bridge (2) Driver DC Motors, General Purpose Power MOSFET 8-SOP
Datasheet
Payment
Delivery
Series
-
Features
-
Interface
Logic
Load Type
Inductive
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Power MOSFET
Applications
DC Motors, General Purpose
Manufacturer
Rohm Semiconductor
Rds On (Typ)
1.5Ohm
Mounting Type
Surface Mount
Package / Case
8-SOIC (0.173", 4.40mm Width)
Voltage - Load
6V ~ 15V
Fault Protection
Current Limiting, Over Temperature, Over Voltage, UVLO
Voltage - Supply
6V ~ 15V
Base Product Number
BD6220
Output Configuration
Half Bridge (2)
Current - Peak Output
-
Operating Temperature
-40°C ~ 85°C (TA)
Supplier Device Package
8-SOP
Current - Output / Channel
500mA
