Raytac MDBT42Q-P512KV2
Images are for reference only
Manufacturer
Manufacturer No
MDBT42Q-P512KV2
Package
41-SMD Module
Packaging
Retail Package
Description
RF TXRX MOD 802.15.4 BT TH SMD
Detailed Description
802.15.4, Bluetooth Bluetooth v5.4, Zigbee® Transceiver Module 2.36GHz ~ 2.5GHz PCB Trace Surface Mount
Datasheet
Payment
Delivery
Mfr
Raytac
Series
-
Protocol
Bluetooth v5.4, Zigbee®
Data Rate
2Mbps
Frequency
2.36GHz ~ 2.5GHz
Packaging
Retail Package
Modulation
-
Memory Size
512kB Flash, 64kB RAM
Sensitivity
-96dBm
Antenna Type
PCB Trace
Mounting Type
Surface Mount
Package / Case
41-SMD Module
Power - Output
4dBm
Voltage - Supply
1.7V ~ 3.6V
Serial Interfaces
ADC, GPIO, I2C, I2S, SPI, PDM, PWM, UART
RF Family/Standard
802.15.4, Bluetooth
Utilized IC / Part
nRF52832
Current - Receiving
3.5mA ~ 12.9mA
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 85°C (TA)
Current - Transmitting
2.7mA ~ 16.6mA
| Attribute | Value |
|---|---|
| Mfr | Raytac |
| Series | - |
| Protocol | Bluetooth v5.4, Zigbee® |
| Data Rate | 2Mbps |
| Frequency | 2.36GHz ~ 2.5GHz |
| Packaging | Retail Package |
| Modulation | - |
| Memory Size | 512kB Flash, 64kB RAM |
| Sensitivity | -96dBm |
| Antenna Type | PCB Trace |
| Mounting Type | Surface Mount |
| Package / Case | 41-SMD Module |
| Power - Output | 4dBm |
| Voltage - Supply | 1.7V ~ 3.6V |
| Serial Interfaces | ADC, GPIO, I2C, I2S, SPI, PDM, PWM, UART |
| RF Family/Standard | 802.15.4, Bluetooth |
| Utilized IC / Part | nRF52832 |
| Current - Receiving | 3.5mA ~ 12.9mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Current - Transmitting | 2.7mA ~ 16.6mA |
