Step1: Product
QT Brightek (QTB) QBLP615-RGB-2943
Images are for reference only
Manufacturer
Manufacturer No
QBLP615-RGB-2943
Availability
In Stock
Package
1206 (3216 Metric)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
LED RGB DIFFUSED 1206 SMD R/A
Detailed Description
Red, Green, Blue (RGB) 620nm Red, 525nm Green, 470nm Blue LED Indication - Discrete 2V Red, 3.1V Green, 3.1V Blue 1206 (3216 Metric)
Datasheet
Payment
Delivery
Mfr
QT Brightek (QTB)
Color
Red, Green, Blue (RGB)
Series
QBLP615
Features
-
Lens Size
2.00mm x 1.00mm
Packaging
Tape & Reel (TR); Cut Tape (CT)
Lens Color
Colorless
Lens Style
Rectangle with Domed Top
Height (Max)
1.10mm
Configuration
Common Anode
Mounting Type
Surface Mount, Right Angle
Viewing Angle
150°
Current - Test
20mA Red, 20mA Green, 20mA Blue
Package / Case
1206 (3216 Metric)
Size / Dimension
3.20mm L x 1.30mm W
Lens Transparency
Diffused
Wavelength - Peak
-
Base Product Number
QBLP615
Millicandela Rating
190mcd Red, 620mcd Green, 110mcd Blue
Wavelength - Dominant
620nm Red, 525nm Green, 470nm Blue
Supplier Device Package
1206
Voltage - Forward (Vf) (Typ)
2V Red, 3.1V Green, 3.1V Blue
| Attribute | Value |
|---|---|
| Mfr | QT Brightek (QTB) |
| Color | Red, Green, Blue (RGB) |
| Series | QBLP615 |
| Features | - |
| Lens Size | 2.00mm x 1.00mm |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Lens Color | Colorless |
| Lens Style | Rectangle with Domed Top |
| Height (Max) | 1.10mm |
| Configuration | Common Anode |
| Mounting Type | Surface Mount, Right Angle |
| Viewing Angle | 150° |
| Current - Test | 20mA Red, 20mA Green, 20mA Blue |
| Package / Case | 1206 (3216 Metric) |
| Size / Dimension | 3.20mm L x 1.30mm W |
| Lens Transparency | Diffused |
| Wavelength - Peak | - |
| Base Product Number | QBLP615 |
| Millicandela Rating | 190mcd Red, 620mcd Green, 110mcd Blue |
| Wavelength - Dominant | 620nm Red, 525nm Green, 470nm Blue |
| Supplier Device Package | 1206 |
| Voltage - Forward (Vf) (Typ) | 2V Red, 3.1V Green, 3.1V Blue |
