Pulse Electronics PH9585.002NLT
Images are for reference only
Manufacturer
Manufacturer No
PH9585.002NLT
Quantity
140
Availability
In Stock
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
XFMR FLYBACK SMD
Detailed Description
Flyback Converters For SMPS Transformer 2250V Isolation 430kHz Surface Mount
Datasheet
Payment
Delivery
Type
-
Style
Wirewound
Series
PH9585.XXXNLT
Footprint
0.252" L x 0.244" W (6.40mm x 6.20mm)
Frequency
430kHz
Packaging
Tape & Reel (TR); Cut Tape (CT)
Applications
Flyback Converters
Manufacturer
Pulse Electronics
Mounting Type
Surface Mount
Intended Chipset
-
Size / Dimension
0.250" L x 0.242" W (6.35mm x 6.15mm)
Voltage - Primary
36 ~ 72V
Voltage - Auxiliary
15V
Voltage - Isolation
2250V
Chipset Manufacturer
-
Height - Seated (Max)
0.142" (3.60mm)
Operating Temperature
-40°C ~ 125°C
Inductance @ Frequency
-
| Attribute | Value |
|---|---|
| Type | - |
| Style | Wirewound |
| Series | PH9585.XXXNLT |
| Footprint | 0.252" L x 0.244" W (6.40mm x 6.20mm) |
| Frequency | 430kHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Applications | Flyback Converters |
| Manufacturer | Pulse Electronics |
| Mounting Type | Surface Mount |
| Intended Chipset | - |
| Size / Dimension | 0.250" L x 0.242" W (6.35mm x 6.15mm) |
| Voltage - Primary | 36 ~ 72V |
| Voltage - Auxiliary | 15V |
| Voltage - Isolation | 2250V |
| Chipset Manufacturer | - |
| Height - Seated (Max) | 0.142" (3.60mm) |
| Operating Temperature | -40°C ~ 125°C |
| Inductance @ Frequency | - |
