Pulse Electronics PE-52646NL
Images are for reference only
Manufacturer
Manufacturer No
PE-52646NL
Availability
In Stock
Package
Radial, Vertical - Corner Terminals
Packaging
Tube
Description
FIXED IND 220UH 1.5A 420 MOHM TH
Detailed Description
220 µH Unshielded Toroidal Inductor 1.5 A 420mOhm Max Radial, Vertical - Corner Terminals
Datasheet
Payment
Delivery
Mfr
Pulse Electronics
Type
Toroidal
Series
-
Ratings
-
Features
-
Q @ Freq
-
Packaging
Tube
Shielding
Unshielded
Tolerance
±20%
Inductance
220 µH
Mounting Type
Through Hole
Package / Case
Radial, Vertical - Corner Terminals
Material - Core
-
Size / Dimension
0.710" L x 0.510" W (18.03mm x 12.95mm)
DC Resistance (DCR)
420mOhm Max
Current Rating (Amps)
1.5 A
Height - Seated (Max)
0.710" (18.03mm)
Operating Temperature
-40°C ~ 130°C
Supplier Device Package
-
Frequency - Self Resonant
-
Current - Saturation (Isat)
-
Inductance Frequency - Test
20 kHz
| Attribute | Value |
|---|---|
| Mfr | Pulse Electronics |
| Type | Toroidal |
| Series | - |
| Ratings | - |
| Features | - |
| Q @ Freq | - |
| Packaging | Tube |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Inductance | 220 µH |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical - Corner Terminals |
| Material - Core | - |
| Size / Dimension | 0.710" L x 0.510" W (18.03mm x 12.95mm) |
| DC Resistance (DCR) | 420mOhm Max |
| Current Rating (Amps) | 1.5 A |
| Height - Seated (Max) | 0.710" (18.03mm) |
| Operating Temperature | -40°C ~ 130°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Current - Saturation (Isat) | - |
| Inductance Frequency - Test | 20 kHz |
