Step1: Product
pSemi PE4251MLI-Z
Images are for reference only
Manufacturer
Manufacturer No
PE4251MLI-Z
Date Code
22+
Quantity
270
Availability
In Stock
Package
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC RF SWITCH SPDT 3GHZ 8MSOP
Detailed Description
RF Switch IC General Purpose SPDT 3 GHz 50Ohm 8-MSOP-EP
Datasheet
Payment
Delivery
IIP3
59dBm
P1dB
30.5dBm
Series
UltraCMOS®, HaRP™
Circuit
SPDT
RF Type
General Purpose
Features
DC Blocked, Single/Dual Line Control
Topology
Absorptive
Impedance
50Ohm
Isolation
43dB
Packaging
Tape & Reel (TR); Cut Tape (CT)
Manufacturer
pSemi
Mounting Type
Surface Mount
Insertion Loss
0.75dB
Package / Case
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
Test Frequency
3GHz
Frequency Range
10MHz ~ 3GHz
Voltage - Supply
3V ~ 3.6V, 4.5V ~ 5.5V
Base Product Number
PE4251
Operating Temperature
-40°C ~ 85°C
Supplier Device Package
8-MSOP-EP
| Attribute | Value |
|---|---|
| IIP3 | 59dBm |
| P1dB | 30.5dBm |
| Series | UltraCMOS®, HaRP™ |
| Circuit | SPDT |
| RF Type | General Purpose |
| Features | DC Blocked, Single/Dual Line Control |
| Topology | Absorptive |
| Impedance | 50Ohm |
| Isolation | 43dB |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Manufacturer | pSemi |
| Mounting Type | Surface Mount |
| Insertion Loss | 0.75dB |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad |
| Test Frequency | 3GHz |
| Frequency Range | 10MHz ~ 3GHz |
| Voltage - Supply | 3V ~ 3.6V, 4.5V ~ 5.5V |
| Base Product Number | PE4251 |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 8-MSOP-EP |
