Step1: Product
Preci-Dip 0907-0-CLIP
Images are for reference only
Manufacturer
Manufacturer No
0907-0-CLIP
Availability
In Stock
Packaging
Bulk
Description
CONTACT SPRING LOADED SMD GOLD I
Detailed Description
Contact Spring Surface Mount
Datasheet
Payment
Delivery
Series
-
Features
-
Packaging
Bulk
Contact Type
Sleeve & Plunger (Pogo Pins)
Manufacturer
Preci-Dip
Plunger Size
0.042" (1.07mm) Dia
Mating Cycles
20000
Mounting Type
Surface Mount
Contact Finish
Gold
Contact Material
Brass
Pad Layout Dimension
Circular - 0.072" (1.83mm)
Current Rating (Amps)
5A
Operating Temperature
-25°C ~ 125°C
Maximum Working Height
0.258" (6.55mm)
Minimum Working Height
0.201" (5.10mm)
Contact Finish Thickness
20.0µin (0.51µm)
Operating Force - Initial
50gf
Recommended Working Height
0.211" (5.35mm)
Material Flammability Rating
-
Operating Force - Mid Compression
90gf
| Attribute | Value |
|---|---|
| Series | - |
| Features | - |
| Packaging | Bulk |
| Contact Type | Sleeve & Plunger (Pogo Pins) |
| Manufacturer | Preci-Dip |
| Plunger Size | 0.042" (1.07mm) Dia |
| Mating Cycles | 20000 |
| Mounting Type | Surface Mount |
| Contact Finish | Gold |
| Contact Material | Brass |
| Pad Layout Dimension | Circular - 0.072" (1.83mm) |
| Current Rating (Amps) | 5A |
| Operating Temperature | -25°C ~ 125°C |
| Maximum Working Height | 0.258" (6.55mm) |
| Minimum Working Height | 0.201" (5.10mm) |
| Contact Finish Thickness | 20.0µin (0.51µm) |
| Operating Force - Initial | 50gf |
| Recommended Working Height | 0.211" (5.35mm) |
| Material Flammability Rating | - |
| Operating Force - Mid Compression | 90gf |
