Step1: Product
Phoenix Contact 1374874
Images are for reference only
Manufacturer
Manufacturer No
1374874
Quantity
224
Availability
In Stock
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
CONN RECEPTACLE 1.27MM 16POS SMD
Detailed Description
16 Position Receptacle Connector 0.050" (1.27mm) Surface Mount Gold
Datasheet
Payment
Delivery
Mfr
Phoenix Contact
Style
Board to Board
Series
-
Features
-
Packaging
Tape & Reel (TR); Cut Tape (CT)
Termination
Solder
Applications
-
Contact Type
Female Socket
Contact Shape
Rectangular
Mounting Type
Surface Mount
Connector Type
Receptacle
Fastening Type
Push-Pull
Number of Rows
2
Pitch - Mating
0.050" (1.27mm)
Voltage Rating
-
Contact Material
Copper Alloy
Insulation Color
Black
Insulation Height
0.356" (9.05mm)
Ingress Protection
-
Insulation Material
Liquid Crystal Polymer (LCP)
Number of Positions
16
Row Spacing - Mating
-
Contact Finish - Post
Tin
Contact Length - Post
-
Current Rating (Amps)
2.1A
Operating Temperature
-55°C ~ 125°C
Mated Stacking Heights
-
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
-
Contact Finish Thickness - Mating
-
| Attribute | Value |
|---|---|
| Mfr | Phoenix Contact |
| Style | Board to Board |
| Series | - |
| Features | - |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Termination | Solder |
| Applications | - |
| Contact Type | Female Socket |
| Contact Shape | Rectangular |
| Mounting Type | Surface Mount |
| Connector Type | Receptacle |
| Fastening Type | Push-Pull |
| Number of Rows | 2 |
| Pitch - Mating | 0.050" (1.27mm) |
| Voltage Rating | - |
| Contact Material | Copper Alloy |
| Insulation Color | Black |
| Insulation Height | 0.356" (9.05mm) |
| Ingress Protection | - |
| Insulation Material | Liquid Crystal Polymer (LCP) |
| Number of Positions | 16 |
| Row Spacing - Mating | - |
| Contact Finish - Post | Tin |
| Contact Length - Post | - |
| Current Rating (Amps) | 2.1A |
| Operating Temperature | -55°C ~ 125°C |
| Mated Stacking Heights | - |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | - |
| Contact Finish Thickness - Mating | - |
