onsemi NCV7703CD2R2G
Images are for reference only
Manufacturer
Manufacturer No
NCV7703CD2R2G
Quantity
409
Availability
In Stock
Package
14-SOIC (0.154", 3.90mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
IC HALF BRIDGE DRVR 1.1A 14SOIC
Detailed Description
Half Bridge (3) Driver DC Motors, General Purpose Power MOSFET 14-SOIC
Datasheet
Payment
Delivery
Series
-
Features
-
Interface
SPI
Load Type
Inductive
Packaging
Tape & Reel (TR); Cut Tape (CT)
Technology
Power MOSFET
Applications
DC Motors, General Purpose
Manufacturer
onsemi
Rds On (Typ)
800mOhm LS, 800mOhm HS
Mounting Type
Surface Mount
Package / Case
14-SOIC (0.154", 3.90mm Width)
Voltage - Load
5.5V ~ 40V
Fault Protection
Current Limiting, ESD, Over Temperature, Over Voltage, UVLO
Voltage - Supply
3.15V ~ 5.25V
Base Product Number
NCV7703
Output Configuration
Half Bridge (3)
Current - Peak Output
-
Operating Temperature
-40°C ~ 150°C (TJ)
Supplier Device Package
14-SOIC
Current - Output / Channel
1.1A
| Attribute | Value |
|---|---|
| Series | - |
| Features | - |
| Interface | SPI |
| Load Type | Inductive |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Power MOSFET |
| Applications | DC Motors, General Purpose |
| Manufacturer | onsemi |
| Rds On (Typ) | 800mOhm LS, 800mOhm HS |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Voltage - Load | 5.5V ~ 40V |
| Fault Protection | Current Limiting, ESD, Over Temperature, Over Voltage, UVLO |
| Voltage - Supply | 3.15V ~ 5.25V |
| Base Product Number | NCV7703 |
| Output Configuration | Half Bridge (3) |
| Current - Peak Output | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 14-SOIC |
| Current - Output / Channel | 1.1A |
